SunCover 4000

SunCover 4000

$2,877.00-$7,750.00

Sitting comfortably between simplicity and sophistication, the SunCover 4000 is a versatile, mid-tier retractable awning that offers increased size, smoother operation, and customizable options while still keeping things DIY-friendly. Perfect for medium to large patios, decks, and outdoor dining spaces, it’s available in wider widths and deeper projections than the 1000, giving you more coverage and more comfort.

The SunCover 4000 introduces motorized operation as an upgrade, along with optional tilt control, allowing users to fine-tune their shade angle throughout the day. Its reinforced frame and smoother glide system offer greater durability and ease of use, and the broad selection of fabric colors and patterns makes it a stylish addition to any exterior.

With the SunCover 4000, you get more shade, more control, and more ways to make the outdoors yours without giving up the DIY spirit.

Retractable Awning Site Survey Checklist Installation Guide
$2,877.00 USD
$2,877.00 USD
Sale Sold out

View full details

Ordering Instructions

Fabric

All models use first-grade 100% acrylic Sunbrella® shade and marine-grade fabric with a 10-year warranty against rot, mildew, and excessive fading.

Stitched with GORE® Tenera thread (8-year warranty).

Note: Patterned/striped fabrics may not align with the main awning due to manufacturing differences or fabric roll widths.

Frame Color

All awnings feature powder-coated aluminum frames (not wet-painted).

Select from standard colors based on the model. Most homeowners choose a color that matches exterior trim.

Valance

Located along the front bar, the valance matches the main fabric and provides added shade.

Stripes and seams will align with the main cover. Several styles available.

4000 model: Includes an 8” wave valance with matching braid.

Mounting

Choose based on your home's structure.

  • Wall Mount – Ideal for flat two-story homes with enough vertical clearance.
  • Roof Mount – Used on ranch and bi-level homes to achieve proper pitch. Brackets install 2 rows back on asphalt shingles (add 12” to roof edge to find mounting height). Requires special roof mount brackets (additional cost).
  • Soffit/Ceiling Mount (4000 only) – Installed under an overhang/eave. No hood required. Check for structural framing behind soffit.

Be sure there are no obstructions (vents, downspouts, exterior lights) in your selected mount area.

Operation

Drive Side – Choose left or right (facing your house from outside).

Manual Crank – Extend/retract by hand (approx. 70 turns for 10’ projection).

Motorized – Plug into an outdoor outlet. Controlled by remote. Stops automatically when fully extended/retracted.

  • Stop at any point for partial shade
  • Includes power cord and remote

Backup manual operation if power is lost

Optional Wind Sensor – Retracts unit automatically if high winds are detected.

Protective Aluminum Hood

An optional powder-coated aluminum hood protects the first 10" of fabric when retracted.

Recommended for roof or wall mounts with less than 2’ of overhead protection.

Do not select a hood for ceiling/soffit mounts.If motorized, a hood can extend motor life and protect fabric from discoloration.

Install with Confidence

View the installation guide for this SunCover awning.

View the Guides
